3D Accelerator – OLD STYLE

Here you can find the history of the 3D accelerator chipsets

Only some data from 1996 – 2006

Rest will follow when I have the time for it

1996
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo Graphics	SST-1	50	4-6
Picture	Chip frequency	Memory frequency
	MHz	MHz
	50	50
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Ati 3D Rage (II)	3D Rage	N/A	2-4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox Mystique	MGA 1064SG	N/A	1-4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
PowerVR PCX1	PCX1	60	4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	60	60
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
S3 Virge serie	Virge/DX	25-33	2-4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	50-66	50-100
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3D Labs Permedia	Permedia	N/A	4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A

1997
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Riva 128	NV3	90	4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	100	100
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo Rush	SST-96	50	4-8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	50	50
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Ati 3D Rage Pro	3D Rage Pro	75	8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	75	100
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox Millenium II	MGA 2164W	N/A	2-16
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox Mystique 220	MGA 1064SG-H	N/A	4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
PowerVR PCX2	PCX2	66	N/A
Picture	Chip frequency	Memory frequency
	MHz	MHz
	66	60
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
SIS 6326	6326	N/A	8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3D Labs Permedia II	Permedia 2	N/A	4-8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A

1998
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo 2	SST-2	180	8-12
Picture	Chip frequency	Memory frequency
	MHz	MHz
	90	90
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo Banshee	Banshee	100	8-16
Picture	Chip frequency	Memory frequency
	MHz	MHz
	100	100
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Riva 128 ZX	NV3	100	8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	100	100
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Riva TNT	NV4	180	8-16
Picture	Chip frequency	Memory frequency
	MHz	MHz
	90	110
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox G100	Twister	66	4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	66	125
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox G200	Exclipse	85	8-16
Picture	Chip frequency	Memory frequency
	MHz	MHz
	85	113
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
S3 Savage3D	Savage3D	90	8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	90	100
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
S3 Trio3D	Trio 3D2X	N/A	4
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Ati 3D Rage 128	3D Rage 128	206	16-32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	103	103
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
PowerVR 250	250	125	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	125
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3D Labs Permedia III	Permedia III	250	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	135

1999
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo 3	Avenger	286-366	16
Picture	Chip frequency	Memory frequency
	MHz	MHz
	143-183	143-183
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Ati Rage Fury MAXX	Aurora	2x 270	2x 32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	135	155
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Riva TNT2 (Vanta/Pro/M64)	NV5	160-286	8-32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	80-143	100-166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Riva TNT2 Ultra	NV5	300	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	150	183
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Geforce 256	NV10	480	32-64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	120	150-166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox G400	Toucan	250	16-32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
S3 Savage4 serie	Savage4 Pro/Pro+	110-166	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	110-166	100-166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
S3 Savage 2000	Savage 2000	500	16-64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	155
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Ati 3D Rage 128 Pro	3D Rage 128 Pro	250	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	143
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
SIS 300	300	N/A	– 64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	143
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Trident Blade 3D	Rcade 3D	N/A	2-8
Picture	Chip frequency	Memory frequency
	MHz	MHz
	N/A	N/A

2000
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo 4 4500	Napalm	333	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	166	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
3dfx Voodoo 5 5500	Napalm	666	2x 32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	166	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Geforce2 GTS	NV15	1600	32/64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	200	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Geforce2 Ultra	NV15	2000	64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	250	230
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Geforce2 (Pro/Ti)	NV15	2000-2500	32-64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	200-250	200
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Nvidia Geforce2 MX	NV11	700	32-64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	175	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Ati Radeon 256	R100	858-996	32-64
Picture	Chip frequency	Memory frequency
	MHz	MHz
	143-183	166-183
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
PowerVR Kyro	STG 4000X	230	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	115	115
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Matrox G450	Condor 1	250	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
Trident Blade XP	Blade XP	333	16-32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	166	166
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte
SIS 305	305	N/A	32
Picture	Chip frequency	Memory frequency
	MHz	MHz
	125	175

2001
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

2002
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

2003
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

2004
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

2005
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

2006
Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz

Name	Codename	Texel fill rate	RAM
		MTexel/s	MByte

Picture	Chip frequency	Memory frequency
	MHz	MHz
